LG UM5N-H Series

The LG UML5N‑H Series (commonly known as UM5N‑H) is a line of 4K UHD standard digital signage displays designed for reliable, high-quality visuals in commercial environments. Here’s a comprehensive overview:

Category:
Description

Key Specifications & Features

  • Display Quality & Build

Resolution: 3840 × 2160 (4K UHD)

Brightness: 500 nits (typical), suitable for bright indoor settings.

Screen Coating: Anti-glare (≈28% haze) improves visibility under strong lighting.

Panel Type: IPS LCD

Sizes Available: 43″, 49″, 55″, 65″

  • Built-in Intelligence

System-on-Chip (SoC): Supports webOS platform, enabling multitasking, app development, and third-party sensor integration—no external media player required.

  • Robustness & Reliability

Conformal Coating on power board protects against salt, dust, humidity, and iron powder.

Ingress Protection: IP5x certified for dust resistance.

Shock Monitoring & Tilt Support: Can tilt up to 30° (typically downward), enhancing flexible installations.

  • Design & Installation

Slim Bezels: 12.4 mm top/bottom, 11.4 mm sides (varies slightly for 43″).

Wall-hugging Mounting: Hidden power inlet, slim bracket allows just ~13 mm clearance from the wall.

  • Security & Compliance

EKP (Enhanced Kernel Protection): Prevents unauthorized access.

ISO/IEC 15408 Common Criteria EAL2 Certified – attests to strong data protection.

  • Content Management & Eco Credentials

SuperSign CMS compatible, plus webOS and third-party apps for remote content control.

Carbon Trust Certified (cradle-to-grave assessment till Sept 2025).

Energy-saving Features: Power-saving modes and EPEAT certification (per datasheet).

  • Connectivity

Inputs: LAN (RJ45), 3× HDMI (4K@60), 1× DisplayPort, USB 2.0, RS‑232C (in/out), Infrared spot, Audio out.

Ideal For:

24/7 Operation: Great for retail stores, transportation hubs, corporate info displays, and public venues

Bright Venues: Anti-glare and high brightness ensure legibility under ambient lighting

Durable Use Cases: Suitable for dusty, humid, or salty indoor environments

Secure Deployments: EAL2 certification and EKP bring enterprise-grade security

Summary Table

Feature UM5N‑H Series
Resolution 4K UHD (3840×2160)
Brightness 500 nits
Haze (Anti-glare) ≈0.28% (0.25% for 43″)
Panel Size Options 43″ / 49″ / 55″ / 65″
Operating System webOS (built-in SoC)
Dust/Water Protection Conformal coating + IP5x dust rating
Security Certification EKP + ISO/IEC 15408 EAL2
Mounting Design Slim bezels, 13 mm wall clearance
Content Management SuperSign CMS, web-based apps
Certifications Carbon Trust, FCC, CE, EPEAT, Energy Star
